A TI-based family of 2.4GHz/5GHz Industrial WiFi & Bluetooth modules are available in compact size from the original manufacturer.
| Module | WG7801-B0 | WG7801-D0 | WG7831-B0 | WG7831-D0 | WG7833-B0 | WG7835V0 | WG7837V0 |
| Chipset | TI WL1801 | TI WL1801 | TI WL1831 | TI WL1831 | TI WL1833 | TI WL1835 | TI WL1837 |
| Wi-Fi | 802.11b/g/n | 802.11b/g/n | 802.11b/g/n | 802.11b/g/n | 802.11a/b/g/n | 802.11b/g/n | 802.11a/b/g/n |
| BT/BLE | N/A | N/A | BT/BLE 4.2 | BT/BLE 4.2 | BT/BLE 4.2 | BT/BLE 4.2 | BT/BLE 4.2 |
| Dimension (mm) | 12.8 x 12 x 1.63 | 12.8 x 12 x 1.63 | 12.8 x 12 x 1.63 | 12.8 x 12 x 1.63 | 12.8 x 12 x 1.63 | 13.3 x 13.4 x 2.0 | 13.3 x 13.4 x 2.0 |
| Temp. | ‐40°C ~ +85°C | ‐20°C ~ +70°C | ‐40°C ~ +85°C | ‐20°C ~ +70°C | ‐40°C ~ +85°C | ‐20°C ~ +70°C | ‐40°C ~ +85°C |
| SISO/MIMO | SISO | SISO | SISO | SISO | SISO | 2.4GHz SISO/MIMO | 2.4GHz SISO/MIMO 5GHz SISO |
| Interface | SDIO | SDIO | SDIO/UART | SDIO/UART | SDIO/UART | SDIO/UART | SDIO/UART |
| Certification | N/A | N/A | N/A | FCC/CE/IC | FCC/NCC/TELEC/ IC/CE |
FCC/CE/IC/TELEC | FCC/CE/IC/TELEC |
| Antenna | External | External | External | External | External | External | External |
