The MDW15 series gives designers the flexibility to match the choice of converter to specific application requirements. The high power density of MDW15 series, at 74W/in3, is expected to make it popular with manufacturers of industrial, transportation and renewable energy equipment where space-constrained is critical. This product offers a full 15 Watt isolated DC-DC converter within a small encapsulated DIP-16 package which occupied only 0.5in2 of PCB space. There are 18 models available for 12, 24 & 48VDC with wide 2:1 input voltage range. Further features included under-voltage protection, overload protection, short circuit protection, very low no load power consumption, no min. load requirement and conducted EMI class A approved as well. High efficiency allows operating temperatures range of -40℃ to 85℃. All models have been qualified per the CB scheme with safety approvals to UL/cUL/IEC/EN 62368-1.
