Smart Home Appliance main control solution

18/09/2023

The NuMicro® M071 series is a 32-bit microcontroller based on Arm® Cortex®-M0 core, with the hardware divider, targeted for smart home appliance applications. For the growing requirements of safety functions on the home appliance, the M071 series provides certified Software Test Library (STL) and an application note for IEC60730-1 Class B Annex H. This certified STL can significantly reduce the development time and efforts to pass IEC60730-1 Class B certification for home appliances. The M071 series runs up to 50/72 MHz and features 2.5V to 5.5V wide operating voltage, -40°C to 105°C wide operating temperature, a variety of packages with wide pin pitch, and excellent high immunity characteristics by ESD HBM 8 kV and EFT 4.4 kV, which greatly meets the rigid requirements for stability, reliability and safety of home appliance systems.

As the new smart function added on home appliances, the M071 series offers up to 256 KB Flash memory for code storage, up to 20 KB SRAM for run time operation and configurable Data Flash memory for parameters.

Main Features

  • Arm® Cortex®-M0 core

- Runs up to 50 MHz

- One 24-bit system timer

- Supports low power sleep mode

- Single-cycle 32-bit hardware multiplier

- NVIC for the 32 interrupt inputs, each with 4-levels of priority

- Serial Wire Debug supports with 2 watchpoints/4 breakpoints

- Built-in LDO for wide operating voltage ranged from 2.5 V to 5.5 V

  • Flash Memory

– 68/36 KB Flash for program code

– Configurable Flash memory for data memory (Data Flash), 4 KB Flash for ISP loader

– Supports In-System-Program (ISP) and In-Application-Program (IAP) application code update

– 512 byte page erase for Flash

– Supports 2-wired ICP update through SWD/ICE interface

– Supports fast parallel programming mode by external programmer

  • SRAM Memory

– 8 KB SRAM

Documents Tech question
