Main Features
CPU Features:
- Operating Voltage:
- fSYS=2MHz: 2.2V~5.5V
- fSYS=4MHz: 2.2V~5.5V
- fSYS=8MHz: 2.2V~5.5V
- Up to 0.5μs instruction cycle with 8MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Oscillators types
- Internal High Speed 2/4/8MHz RC – HIRC
- Internal Low Speed 32kHz RC – LIRC
- Fully integrated internal oscillators require no external components
Peripheral Features:
- Flash Program Memory: 4K×16
- RAM Data Memory: 384×8
- True EEPROM Memory: 64×8
- Watchdog Timer function
- In Application Programming function – IAP
