Main Features
- Board type : Pluggable SOM
- 5-Cent Cooling available
- CPU details: Quad ARM Cortex-A53 up to 1.6 GHz, Single ARM Cortex-M7 up to 800 MHz
- CPU vendor : NXP
- CPU type: Cortex-A53, Cortex-M7
- Co-processor available
- Number of cores : 5
- GPU available
- GPU type: 2D / 3D graphics accelerator
- PMIC : PCA9450CHN
- Features: Neuronal Processing Unit (NPU) with 2.3 TOPS to accelerate machine learning inferences, two camera inputs and HDR ISP, enhanced multimedia capabilities (encode and decode H.265 and H.264 at 1080p 60fps)
- Security: Widevine and PlayReady DRM content protection, public Key Cryptography with RSA and ECC algorithms, TrustZone, Resource Domain Controller with 4 domains and 8 regions, Secure Boot / High Assurance Boot (HAS)
- LPDDR4 DRAM 1: 1 / 2 / 4 / 8 (on request) GB
- E2Prom: 256 Byte
- microSD available
- External RTC available
- Bluetooth available
- Bluetooth version: Bluetooth® v5.0 (BR/EDR/BLE) with chip antenna or U.FL connector
- WiFi available
