Workstation-grade fanless embedded system

27/11/2020

Powered by 10th generation 10-core Intel® Xeon®/Core™ i9/i7/i5/i3 processor (Comet Lake), running with Intel® W480E Chipset, fanless -40°C to 75°C operating temperature, multiple 2.5GigE/10GigE RJ45/SFP+ Fiber LAN, max 6 USB 3.2 connections supporting up to 10Gbps data rate, outstanding system performance, 5G/WiFi/4G/3G/LTE/GPRS/UMTS mobile availability, 9V to 50V power input with 80V surge protection, ignition power control, smart circuit protection and rugged reliability in harsh environments, all-in-one integrated features, Vecow ECX-2000 Series Fanless Embedded System is your new generation choices for Factory Automation, Intelligent Vending, Intelligent Transportation System (ITS), Robotic Control, AMR/AGV, Deep Learning, any Artificial Intelligent oriented AIoT or Industry 4.0 applications.

Documents Tech question
6218 1

Workstation-grade fanless embedded system

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents
  • Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (CML-S) running with Intel® W480E chipset supports max 95W TDP CPU
  • 2 DDR4 2933MHz Memory supports up to 64GB, optional with ECC
  • 9V to 50V wide range DC Power Input with 80V Surge Protection
  • Fanless, -40°C to 75°C Operating Temperature
  • 9 Independent GigE LAN with 4 IEEE 802.3at PoE+
  • Nano SIM Sockets for 5G/WiFi 6/4G/3G/LTE/GPRS/UMTS
  • Expansion : 1 M.2 Key B, 1 M.2 Key E, 1 Mini PCIe, optional SUMIT A, B
  • 6-port USB 3.2 supports up to 10Gbps data transfer
  • Front Access : 2 2.5″ SSD Tray, 2 Nano SIM Socket, 1 Micro SD Card
  • Supports Configurable Software Ignition Power Control and TPM 2.0
  • Optimized user-friendly design for easier system maintenance
  • Supports multiple Ethernet Configuration options such as: 10G LAN/2.5G LAN/10G SFP+/1G SFP
  • Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications
