Main Features
- High sensitivity (up to 500 mV/V/mT)
- Large signals (200 mV/V typical full-scale)
- Flexible 0 to 10 V supply (no minimum)
- 20 kiloohm device resistance for low power
- High linearity (1% of full-scale)
- Ultra-low output temperature coefficient (±0.1%/°C)
- Up to 300 kHz bandwidth
- –40 to 125 °C operating range
- 2.5 x 2.5 mm DFN6 package
