Nowadays, the trend of having an electric vehicle as transportation is steadily growing. Including private transport and public transport, more and more of it are powered by electricity. On the other hand, the demand of EV charging stations have also increased rapidly. Therefore, APLEX offers a rugged and stable HMI ARCHMI-8B series, which is well suited for EV charger solution.
ARCHMI-8B is the fanless industrial HMI series that powered by Celeron J6412 from Elkhart Lake platform.
ARCHMI-8B comes with 7”, 10.1”, 15”, 21.5” TFT-LCD and more sizes are coming soon. It is highly integrated with various applications by featuring with multiple I/O interfaces, including 2 x USB 3.2, 2 x USB 2.0, 1 x COM, 1 x DP and 2 x 2.5GbE LAN. Nevertheless, it also offers expansion card – TB528 series for additional functionality and capability like USB, COM, LAN, CAN bus module and Mini-PCIe interface, etc.
Expect for the specification, ARCHMI-8B has IP66 rated front bezel and flat front touch screen with resistive touch and projective capacitive touch. Constructed by aluminum die-casting chassis and featuring wide range operating temperature from 0°C ~ 50°C (-20°C ~ 60°C for option). However, with add-on features of auto dimming, optical bonding, AR coating and high brightness solution, it is particularly perfect for semi-outdoor application, like EV-charger, kiosk and ATM.
APLEX Technology Inc. is one of the leading brands in industrial computer products. The company is dedicated to satisfying customer’s needs by offering comprehensive solutions and applications.
