Small Form Factor Inertial Measurement Unit (IMU) With 6 Degrees of Freedom

19/05/2023

Triaxial angular rates and linear accelerations, provides high-stability and high-precision measurement capabilities with the use of high-precision compensation technology.

A variety of calibration parameters are stored in the memory of the IMU, and are automatically reflected in the measurement data being sent to the application after the power of the IMU is turned on. With general-purpose SPI/UART support for host communications, the M-G366PDG0 reduces technical barriers for users to introduce inertial measurement and minimizes design resources to implement inertial movement analysis and control applications. The features of the IMU such as high stability, high precision, and small size make it easy to create and differentiate applications in various fields of industrial systems.

Contact Alcom for datasheets and more information

Main Features

  • Small size & Light Weight: 24 x 24 x 10 mm3, 10 g
  • Low-Noise, High-Stability
    Gyro Bias Instability:1.2 °/ h
    Angular Random Walk: 0.08 °/√h
  • Calibrated Stability (Bias, Scale Factor, Axial Alignment)
  • Interface: SPI / UART
  • Calibration Temperature: −40 °C to +85 °C
  • Power Supply Voltage: 3.3 V
Documents Tech question
Epson G366

Small Form Factor Inertial Measurement Unit (IMU) With 6 Degrees of Freedom
