Product news

Pulse introduced its first LLC transformer specifically designed for SiC/GaN device switching. The PMT6709NL delivers 2W of power which can be configured with LLC controllers such as the TI UCC25800-Q1 or the MPS MPQ18913 to provide positive and negative outputs for robust switch on/off. The extended creepage UI5 platform provides 3.75kVrms Hi-Pot isolation voltage in a compact (17.2x11x8.5mm max) SMD platform. This IATF design is compatible with full winding automation to fulfil the requirements of high reliability in automotive applications.

Designed for applications such as inverter motor drives that are driven by high voltage batteries, this platform satisfies the 9.1 mm min creepage requirement of IEC 61558-1 for basic insulation and a working voltage up to 850Vrms, or up to 450Vrms working voltage for applications that require reinforced insulation. A split bobbin is use to keep the interwinding capacitance to less the 2.5pF.

Electric Vehicles (EVs), generally refer to cars with electric motor powered by battery rather than internal combustion engine powered by gasoline.

HONGDA Capacitors, qualified manufacturer with ISO9001, IATF16949, produce various inductors.

Magnetics: LD2-High Voltage metalized unshielded drum core inductor, WCLA2520/WCLA3225 Automotive Chip Inductors, EPM Isolated DC to DC Converter, ...

Pulse continues to expand our portfolio of inductors used to power processors, memory, FPGAs and ASICs in servers, datacenters and storage systems.

Taoglas is expanding its Advanced Components portfolio by launching a full range of Magnetics for network communications: RJ45 Integrated Connectors (Atmos Series), LAN Transformers (Exos Series) and BMS Transformers (Stratos Series).

Pulse has expanded its range of high-power catalogue flyback transformer in the EFD15+ package with the introduction of the PAT6261 series.

The main function of the circulator is to ensure the signal lossless passes forward, as well al block of the reflected signal via high isolation

Pulse is excited to announce the launch of an automotive grade IATF certified version of our popular PH9505 series of high isolation current sense transformer, which remains same platform and footprint size with PH9505

Elegant and reliable solutions for touchscreens

Our surface-mounted power inductors are designed for applications ranging from power supply to power converters.

Pulse Electronics’ newest BMS transformers, at 3.45mm high, are the markets lowest profile packages and complement the current BMS range of products.

Market leading PulsejackTM, integrated connector modules (ICMs) for high speed 10GBase-T over copper are now expanded with the introduction of the JXT4- family.

Pulse Electronics' modules with 40 W and 70 W PoE are designed for outdoor and industrial environments

Electric Vehicles (EVs), generally refer to cars with electric motor powered by battery rather than internal combustion engine powered by gasoline.

Eaton’s broad selection of high Q chip inductors provides design flexibility in many RF wireless applications in multilayer and wire-wound configurations, with industry sizes 0603 to 1206 (MCQ family), 0402 to 0805 (MCL family), and 1008 and 1210 (WCL family).

The Watts range for the standard core type EP is 3W-70W. For the low-profile core shape EFD this Is 8W-90W. The wattage from 3W to 90W.

A new PAS6322 series of low-profile current sense transformers become part of the company’s diverse line of current sense transformers depicted above (PAS6322 not shown).
