New Touch Flash MCUs series

02/09/2022

The BS82C16CA and BS82D20CA series have improved noise immunity and provides a higher range of system resources. The package types are fully compatible with the predecessor devices, the BS82C16A-3 and BS82D20A-3. These features combine to ensure that the devices are suitable for use in touch key applications which require an LCD/LED display, such as induction cookers, microwave ovens, electric heating tables, etc.

The devices provide 16/20 touch keys all of which have passed conductive susceptibility 10V dynamic testing. The devices have a wide range operating voltage of 1.8V~5.5V, a 4K×16/8K×16 Flash Program Memory, a 512×8/768×8 RAM and a 512×8 EEPROM. With regards to peripheral features, the devices also include a software LCD function, an LED driver, a high speed UART interface and an I²C interface.

The devices are supplied in 24-pin SOP/SSOP, 28-pin SOP/SSOP and 48-pin LQFP package types. Holtek also fully supports the devices with a comprehensive suite of hardware and software development tools as well as a touch key function library which enables designers to develop their products more rapidly.

Main Features

CPU Features:

  • Operating voltage
  • fSYS=8MHz: 1.8V~5.5V
  • fSYS=12MHz: 2.7V~5.5V
  • fSYS=16MHz: 3.3V~5.5V
  • Up to 0.25μs instruction cycle with 16MHz system clock at VDD=5V
  • Power down and wake-up functions to reduce power consumption
  • Oscillator types
  • Internal High Speed 8/12/16MHz RC – HIRC
  • External Low Speed 32.768kHz Crystal – LXT
  • Internal Low Speed 32kHz RC – LIRC
  • Multi-mode operation: FAST, SLOW, IDLE and SLEEP

Peripheral Features:

  • Flash Program Memory: 4K×16~8K×16
  • RAM Data Memory: 512×8~768×8
  • True EEPROM Memory: 512×8
  • Up to 20 touch key functions – fully integrated without requiring external components
  • Watchdog Timer function
  • Up to 42 bidirectional I/O lines
