Main Features
FPGA Fabric Architecture
- Up to 138K LUTs(GW5A(T)-138)
- Up to 23K LUTs(GW5A-25)
- Block SRAM with multiple modes
- Single Port, Semi-Dual Port, True Dual Port, and Semi Dual Port with ECC function
- Byte write enable
- ECC error detection and correction
Flexible GPIO
- Adjustable drive strength
- 4mA, 8mA, 12mA, 16mA, 24mA drive
- Bus keeper, pull up/down and open drain
- Hot Socket and input hysteresis
ADC
- 60dB SNR and 1kHz Signal Bandwidth
- Flexible X-channel oversampling ADC
- No external voltage source required
Configuration & Programming
- JTAG, SSPI, MSPI, CPU, and SERIAL
- Background programming
- SPI Flash Programming and Boot
- Multi-boot
High Speed Interfaces
- SERDES(GW5AT-138)
- 270Mbps-12.5Gbps operation
- CDR (Clock Data Recovery)
- Dedicated RX and TX Channels
