Highly Customizable, Modular CNC Solution - OTC

10/06/2022

Avalue’s innovative modular HMI system OTC is a highly customizable and integrable HMI control system designed for the manufacturing industry. Providing continuous upgrades for smart factories, improving stability and optimizing allocation and monitoring, OTC is ideal for applications such as digital central control system for CNC machines and HMI for production automation.

The central control system is the core of factory automation. To maintain efficacy, precision and reliability, the manufacturing process must be monitored in real time with highly responsive allocation of resources. This will ensure safety during the production process, effectively reduces human error, energy consumption and raw material depletion, and improves equipment utilization and labor productivity. By integrating embedded touchscreen computer and highly customizable modular control panel, Avalue provides a HMI system solution that is high integrable with a simple and intuitive operating interface and highly expandable functions, creating a brand-new automated factory control system with flexible production structure.

Main Features

  • x86 PC Based Platform (Intel ATOM, Core i Processor)/ ARM Based Platform (Rockchip, NXP)
  • Full Flat Front Panel with Projected Capacitive Touch Supports Multi Touch
  • 10.1"~21.5" Screen Size depend on Select Model
  • USB3.0, RS-232/422/485, Gigabit LAN
  • Available Expansion for Audio, USB, COM, HDMI, MPCIe, GPIO, CAN Bus
  • Physical Buttons Support (Emergency Stop, On/Off, Handwheel, MPG Encoder)
  • Wide Voltage +12V ~ +26V or +9V~+36V Input, ErP Power
  • IP65 Compliant Front Panel, IP67 for Control Panel Button, Oil-Resistant
  • CNC Machine Operator Control Panel Support for FNAUC, Mitsubishi, Fagor
  • Panel Encryption, PLC Program Circuit Board Customized
