Compact integrated solution with the latest Intel Atom x6000E Series processor

17/09/2021

The solution comprises SPC-6000 and PBC-1000 Ultra-compact Fanless Embedded Box PC, and EPBC-1000 2.5" Single Board Computer. Powered by Intel Atom® x6000E Series processor, Vecow compact integrated solution brings power-efficient, enhanced graphics performance and flexibility capabilities to empower the edge applications such as Intelligent Control, Energy Management, M2M, In-Vehicle Infotainment, factory Automation, and any AIoT/Industry 4.0 applications.

Vecow SPC-6000 and PBC-1000 are ultra-compact fanless embedded with energy-efficient innovations in a small form factor. Based on Intel Atom® x6000E Series Processor, Vecow brand-new ultra-compact fanless embedded Box PC delivers up to 40% faster computing and two times improved 3D graphics performance than the former generation solution.

Vecow EPBC-1000 is a 2.5" Pico-ITX SBC based on Intel Atom® x6211E processor and allows low-power consumption with up to TDP 6W.

Main Features

SPC-6000 Ultra-compact Fanless System:

  • Quad-core Intel Atom® x6425RE processor (Elkhart Lake) delivers up to 40% faster compute and up to 2X better 3D graphics performance than the former generation solution
  • Fanless, -40°C to 70°C operating temperature
  • DDR4 3200MHz memory, up to 32GB
  • DVI-I and DisplayPort dual display supports up to 4K resolution
  • 1 Independent 2.5GigE LAN supports Intel® Time Coordinated Computing (TCC) and Time Sensitive Networking (TSN) for real-time data synchronization
  • 1 Independent Gigabit Ethernet Controller supports 10/100/1000 Mbps data transfer
  • 2 USB 3.1, 2 USB 2.0, 4 COM RS-232/422/485
  • External Nano SIM socket supports 5G/WiFi/4G/3G/LTE/GPRS/UMTS
  • 12V DC Power Input
  • Supports Software Ignition Power Control and TPM 2.0
  • Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

PBC-1000 Ultra-compact Fanless System:

  • Intel Atom® x6000 Series Processor delivers up to 40% faster compute and up to 2X better 3D graphics performance than the former generation solution
  • Small form factor, ultra-compact design
  • Fanless, -40°C to 70°C Operating Temperature
  • 2 GigE LAN, 2 USB 3.0, 2 COM, M.2 Key B, M.2 Key E
  • SIM Socket for WiFi/5G/4G/LTE/GPRS/UMTS
  • Optional VHub AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

EPBC-1000 Industrial Motherboards:

  • Dual-core Intel Atom® x6211E Processor (Elkhart Lake), TDP 6W
  • 2.5" Pico-ITX compact size, Small Form Factor (SFF), measure only 100 x 72 mm
  • Supports fanless -40°C to 70°C Operation
  • 1 DDR4 3200MHz SO-DIMM, up to 32GB
  • DisplayPort supports up to 4K resolution
  • 2 GigE LAN, 2 USB 3.1, 2 COM
  • SIM Socket for 5G/WiFi/4G/LTE/GPRS/UMTS
  • Expansion : M.2 Key B, M.2 Key E
Documents Tech question
Vecow Compact Integrated Solution2

Compact integrated solution with the latest Intel Atom x6000E Series processor

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

  • 7 Io T Industry 4 0

    IIoT & Industry 4.0

  • 18 Traffic Transportation

    Traffic & Transportation

Technologies

  • Shutterstock 660745639

    Industrial & embedded motherboards

Vecow

Vecow is committed to designing, developing and producing industrial-grade computer products; all of them are leading in performance, trusted in reliability, exhibit advanced technology, and innovative concepts.

Read more
Vecow logo

Documents

  • Vecow SPC 6000 Datasheet
  • Vecow PBC 1000 Datasheet
  • Vecow EPBC 1000 Datasheet
