Automotive SAM with New Family Precision Timing Solutions

28/10/2022

SiT1881 is an ultra-low-power 32 kHz oscillator family that provides accurate time keeping for advanced driver assistance systems (ADAS), infotainment, instrument clusters and electronic control units (ECUs). The unique combination of 4x better stability and up to 20% lower power extends system battery life.

Main Features

  • Stability: ±50 ppm frequency stability over entire temperature range ensures robust system performance in hostile environments and lower power consumption
  • Ultra-low power: 490 nA current (<0.6 µW typical power consumption)
  • Industry’s smallest form-factor: 1.2 mm x 1.1 mm x 0.55 mm QFN package (1.32 mm2 footprint, 0.67 mm3 volume)
  • AEC-Q100 Grade 2 qualified with extended -40 oC to +105 oC temperature range
  • Superior reliability: 2 billion hours MTBF
  • Industry’s smallest, ultra-low power 32.768 kHz automotive XO designed to operate over a wide voltage and temperature range
Documents Tech question
Si Time Si T1881

Automotive SAM with New Family Precision Timing Solutions

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 3 Automotive

    Automotive

  • 7 Io T Industry 4 0

    IIoT & Industry 4.0

Technologies

  • Screenshot 2022 05 04 130706

    Timing & frequency control

SiTime

SiTime Corporation is the leader in MEMS-based timing. Transforming the timing industry with configurable solutions that replace legacy quartz devices SiTime enables differentiation of products with the higher performance, smaller size, lower power and beter reliability.

Read more
Si Time Logo

Documents

  • Si Time Si T1881 datasheet
