ATX Server Board Based on Latest 4th Generation Intel® Xeon® SP CPU

31/03/2023

The HPM-SRSUA, server-grade ATX motherboard that supports the Intel 4th Generation Xeon SP Sapphire-Rapids LGA4677 single-socket platform.

The HPM-SRSUA offers 6x DDR5 4800 RDIMM memory support for up to 1.5 TB featuring 50% faster bandwidth, 4x PCIe 5.0 x16 slots, and 3x PCIe 5.0 x4 slots. It allows up to 4x full-height and double-wide GPGPU cards. The server board increases I/O throughput up to 2.5X as compared to the company’s previous generation. Users can easily upgrade as their needs expand.

For storage, there are 5x SATA III (6-Gbit/s) ports with RAID functionality, as well as 1xM.2 M-Key slot to support NVMe SSDs. In addition, the interface includes 4x USB 3.2 Gen1, 2x USB 2.0 type A, 1x COM and 1x VGA. Dual 10-GbE Ethernet ports increase the transfer rate between computing nodes and further boost overall performance.

Using the baseboard management controller (BMC) and intelligent platform management interface (IPMI2.0), an administrator can access the system remotely 24/7, to adjust startup settings, real-time system health diagnostics, firmware, OS upgrades, and prearranged predictive maintenance.

Main Features

  • Intel LGA4677 Socket supports 4thGen. Intel Xeon Scalable Processor (Max. TDP at 250W)
  • Intel® C741 Chipset
  • 6 x DDR5 4800/ 4400 MHz RDIMM up to 1.5TB
  • TPM 2.0 onboard
  • IPMI 2.0 with AST 2600 BMC controller onboard
  • 1 x Intel I210AT 1Giga-bit Ethernet
  • 1 x Intel I226-LM 2.5Giga-bit Ethernet
  • 1 x Intel X550-AT2 10Giga-bit Ethernet(Optional)
  • 5 x SATA IIISupport RAID 0,1,5,10
  • 1 x internal RS232 port
  • 4 x USB 3.2 Gen1 port & 2 x USB 2.0 port at Edge I/O
  • 4 x internal USB 3.2 Gen1 Port
  • 1 x M.2 M-Key PCIe 3.0 x4 NVMe SSD, 2242/2260/2280/22110 form factor
  • 12" x 9.6" (304.8mm x 243.84mm), PCB thickness is 2.54mm
