Advanced Embedded Video Engine ICs

01/10/2021

The new BT817 and BT818 series represent the fourth generation of EVE products, and follow the already established mantra of helping those with little or no relevant prior experience to build advanced HMIs with high degrees of differentiation.

These new functionally-superior graphic controller ICs are intended for use in retail, digital signage and office management systems, as well as public information units, vending machines, domestic appliances, store/mall direction finding systems, training/educational equipment and interactive exhibits. They are able to address the requirements of HMIs rendered on much larger format displays and offer greater resolution levels too.

EVE technology is a revolutionary concept that utilizes an object oriented methodology for creating hi-quality human machine interfaces (HMIs). With support for display, audio, and touch, this new technology allows engineers to quickly and efficiently design HMIs and deliver robust solutions, hi-resolution displays with lower bill of material costs.

Building on the success of the first three generations of FT8xx touch display controller ICs with Embedded Video Engine (EVE) technology, the series has now been extended to include a further two graphics controller devices which offer a plethora of improvements and extended capabilities, the BT81x series.

Main Features

  • Graphic control, audio control, and touch control interface
  • Supports multiple widgets
  • Built-in graphic operations
  • Supports Adaptive Scalable Texture Compression (ASTC) format
  • Supports 4-wire resistive touch screen (BT818) or capacitive touch screen with up to 5 touch point detection (BT817)
  • Enhanced sketch processing
  • Built-in 12MHz crystal oscillator with PLL providing programmable system clock up to 72MHz
  • 1920x480, 1440x540, 1280x800, 1024x600, 800x600, 800x480, 480x272, 320x240 Supported LCD resolutions
  • Supports I/O voltage from 1.8V to 3.3V (5V tolerant)
  • Internal voltage regulator supplies 1.2V to the digital core
  • Video RGB parallel output; configurable to support PCLK up to 96MHz with separate PLL(PLL2), and R/G/B output of 1 to 8 bits (including RGB565, RGB666, and RGB888)
  • Supports playback of motion-JPEG encoded AVI videos
  • Mono audio channel output with Sigma-delta
  • Built-in sound synthesizer
Documents Tech question
Bridgetek BT817 BT818 Q

Advanced Embedded Video Engine ICs

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents
Bridgetek BT817 818 Feature List 1

Applications & Markets

  • 13 AV Broadcast

    A/V & Broadcast

  • 16 Kiosk POS Digital Signage

    Kiosk, POS & Digital Signage

  • 4 Medical Healthcare Fitness

    Medical, Healthcare & Fitness

  • 27 White Goods Home Appliances

    White Goods & Home Appliances

Technologies

  • Shutterstock 1666017652

    Audio, video, multimedia

Bridgetek

Bridgetek is a leading global semiconductor company providing high performance microcontroller units (MCUs), display IC products and developing innovative silicon solutions that enhance seamless interaction with latest connectivity technologies.

Read more
Bridgetek Logo

Documents

  • Bridgetek BT817 BT818 Datasheet
