5G Sub-6GHz and mmWave module

17/11/2023

Fibocom FG190/FM190 is a series of 5G Sub-6GHz and mmWave module, designed to bring outstanding cellular performance to mass data transmission applications such as mobile broadband, FWA, enterprise 5G, and IIoT. The module series adopts the advanced technologies in RF design, baseband, antenna interface and software, allowing industry customers to evolve with the latest innovations.

Region: Global*

Fibocom FM190-GL is a 5G Sub-6GHz Module compliant with the 3GPP Release 17 standard. Powered by the Qualcomm Snapdragon SDX75, it supports both 5Gstandalone (SA) and non-standalone (NSA) network architectures, which provide superior 5G experience connectivity and delivers optimized power consumption benefits for IoT applications.

The module is in an M.2 form factor with dimensions of30*52*2.3mm, which offers up to 300MHz bandwidth and downlink NR 5CA, FDD+FDD uplink carrier aggregation, and FDD uplink MIMO in the NR Sub-6GHz, which delivering a high-speed experience in the home, enterprise and manufacturing plants. The FM190W-GL features rich network protocols and integrates multiple interfaces, including USB 3.1/3.0/2.0, PCIe 4.0/3.0, I2S, and more.

Main Features

Package

M.2

Dimension (mm)

30x52x2.3

Sub-6

n1/2/3/5/7/8/12/13/14/18/20/25/26/29/30/34/38/39/40/41/46/48/53/66/
67/68/70/71/75/76/77/78/79/90/91/92/93/94

mmWave

NA

UMTS

LTE FDD

B1/2/3/4/5/6/8/9/19

B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/70/71/75/76

LTE TDD

B34/38/39/40/41/48/46/53

CDMA

B0/1/10

Operation mode

NSA&SA
